Up-Stream Facilities

On-Upstream of the Oil & Gas Industry, Plants process water more than Oil & Gas by volume. Production of 1 ton crude oil requires around 5 ton water.

Injection of water or Fracking is used to extract oil and gas from deposits can be supplied after treatment from seawater, waste water and brackish water by applying MAT water treatment equipment technology.

Intake Water Treatment Facility & Equipment
Intake Water Treatment Facility & Equipment

Intake Water Treatment Facilities

Main source of water injection or fracking of oil and gas plants is seawater. Since seawater intake contains high sulfate compound precipitations, scaling usually occurs in the circuit. Using proper technology by removing sulfate from the intake injection water, scaling and sour water is minimized or even eliminated. Portions of the Nano filtered water is treated by Reverse Osmosis, supplying fresh water for utilities, rinsing and back washing of nano-filtration membranes and others.

“Produced Water” Re-Use

The largest by-product of oil and gas production is, the “Produced Water” which with today’s technology can be treated for reuse or pass through to environmental safe discharge purposes. Following the current environmental directives as well as ISO operational standards, MAT offers filtration solutions to protect refinery equipment, processes and ensure productivity. Discharged water is kept within the discharge permissible limits of each county, achieving the limits using MAT technology.

The Oil and Gas industry is continuously working to decrease its dependency on water by minimizing its use, facilitating reuse and improving effluent treatment technologies.

In addition to “Produced Water”, the refinery process in Oil and Gas, requires the usage of large volume of water, and equivalently treatment of the waste water is demanded in several internal processes.

Water treatment is essential to enhance water recovery and minimize the environmental impact of oil and gas production as well as, to protect fuel wells, equipment and processes.

Produced Water can be transformed to usable water by means of proper treatment processes. After rough screening, through oil & water separation equipment gloated solid particles, oil and gasses get separated. Fine particles may be separated via media-filtration, micro filtration and ultrafiltration according to required water parameters set. Adsorbent filters are utilized to retain dissolved hydrocarbons in the water. After oil and particles are removed from water; ion-exchange, softener, nano filtration and reverse osmosis are applied to separate ions and other contaminants from water.

Proper treatment trains and efficient equipment selection allow water recovery up to 75-85% of the “Produced Water” with targeted quality water parameters enabling reuse in processes or safely discharge.

Oil and Gas Downstream Water Treatment Application
Oil and Gas Downstream Water Treatment Application

Oil & Gas Industrial Water Treatment Equipment

Oil Skimmers

Oil Skimmers

Industrial Bag Filters

Industrial Bag Filters

Air & Dirt Separators

Air & Dirt Separators

Dissolved Air Flotation Systems

Dissolved Air Flotation Systems

Pump Intake Reservoir Screens

Pump Intake Reservoir Screens

Strainers

Strainers

Cartridge Filters

Cartridge Filters

Cooling Tower Water Filtration Skids

Cooling Tower Water Filtration Skid Systems

High Flow Self-Cleaning Filters

High Flow Self-Cleaning Filters

Industrial Self Cleaning Filters

Industrial Self Cleaning Filters

Heavy Duty Self Cleaning Filters

Heavy Duty Self Cleaning Filters

Micro Fiber Self Cleaning Filters

Micro Fiber Self Cleaning Filters

Oil & Gas Water Treatment Solutions

  • Screening
  • Sedimentation & Clarification
  • Precipitation
  • Media Filtration
  • Automatic Self-Cleaning Filtration
  • Membrane Filtration (UF & R/O)
  • Demineralization Units
  • Sludge Conditioning, De-Watering & Drying
  • Softening
  • De-Ionization & Electro De-Ionization
  • Ion Exchange
  • Sludge Conditioning, De-Watering & Drying
  • Oil-Gas-Water Separators (API & CPI)
  • Dissolved Gas Flotation Units
  • Membrane Oil Separation
  • Nanofiltration (SO2 removal)
  • Aerobic Biological Treatment Units
  • Membrane Bio Reactors
  • Sour Water Strippers (H2S, NH3)
  • Condensate Polishing

Down-Stream Facilities

On-Downstream of the Oil & Gas Industry refined products are produced in refineries. Recirculated water is the blood of the refineries for steam, distillation, cooling and condensing processes. Boiler water, Industrial waste water and selective matter treatment are complicated processes of downstream water re-use systems.

Water treatment and re-use systems are essential parts of water management of Refineries after “at source reduction”, “Segregation of Streams” and “good housekeeping” guidelines.

Industrial Water Treatment Equipment for Downstream Facilities
Industrial Water Treatment Equipment for Downstream Facilities
Modular oil treatment separation unit
Modular oil treatment separation unit

MAT uses the below water treatment train logic for the most efficient recovery results based on the conditions of reusable water;

  • Automatic Self-Cleaning Filters
  • Gravity Separation of bulk oil/solids (API, CPI)
  • Flocculation & Clarifiers
  • Aerobic Bio Treatment of Dissolved Species (Trickle, RBC, MBR, AST)
  • Dissolved Air Flotation (DAF)
  • Polishing Treatment (Media Filters, Micro Filtration, AC, UF)
  • Desalting (ED, NF, RO)

Refineries Water Re-Use Applications

Industrial Recycling and ReuseBoiler feed water, Fire protection, Cooling tower, Process water, Manufacturing, Vehicle washing, Dust control
AgricultureIrrigation
HusbandryLive Stock
AquacultureLand Based Fish Farms
LandscapeIrrigation
Groundwater RechargeGroundwater replenishment (water banking), Salt water intrusion control, Subsidence control
RecreationLakes, streams and ponds, Snow making
Non Portable Urban UseFire protection, Air conditioning, Toilet flushing
Potable UseBlending in water supply reservoirs, Blending in groundwater, Direct pipe to pipe water supply
Oil Industry Water Formation Process
Oil Industry Water Formation Process

MAT design and fabricate water treatment equipment, provide commissioning and operator training for customized SKID systems providing trouble free installation, even within limited spaces, such as on off shore oil and gas rigs. The range of MAT equipment for this application is:

  • Cooling & Boiler Water Treatment
  • Crude Oil Recovery
  • Injection Water Treatment
  • Water-Reuse
  • Effluent Treatment
  • Refining Process Water Treatment
